Cold Cathode UV Lamp(U-Shaped)
發(fā)布于：22-12-09
隸屬于：Quartz Cold Cathode UV Lamp
Figure and specification of Quartz Cold Cathode UV Lamp
U-Shaped（Fig4）
U-Shaped（Fig5）
Specification of Quartz Cold Cathode UV Lamp
| Specification | Bulb dia(mm) | Overall length(mm) | Tube Voltage(V) | Tube Curtent(mA) | Power(W) | Strength of the Ultraviolet light | Life(h) | Note |
| U-Shaped | φ 4 | 45×2 | 220-260 | 2-3 | 0.6-0.8 | 3800 | 10000 | Fig4、5 |
| φ 5 | 55×2 | 220-250 | 3-4 | 0.8-1.0 | 4000 | 10000 | Fig4、5 |
* There are many kinds of ultraviolet lamps with uses.they can be provided in a complete set with other components and materials.As for lamp tubes, both straight tube & other shapes are available.Customers can choose at will.
